- Stable and Uniform Hot Air Heating System
Lower Heater Adjustable
Carbon Fiber Micro-crystalline Infrared Preheater
External Air (N2) Supply Control System
High-Precision PID Temperature Control System
Automatically High-Precision Optical Alignment System
Industrial High-Definition CCD (2.0 MP)
HD Touch Screen HMI Interface
Automatic Placement, Desoldering
Built-In Pressure Testing Device To Protects The PCB
Real-Time Temperature Monitoring and Over-Temperature Protection
Emergency Stop Function
SMD Feeding Device Support (Optional)
Add a side camera, more clearly observe the rework process(Optional)
Application
Suitable for Normal SMD(BGA, QFP etc.) & Micro-SMD Components Repair, Support P08 Small pitch LED beads, Min. 0.5mm * 0.5mm IC.
| Greutate | 128 kg |
|---|---|
| Dimensiuni | 100 × 84 × 95 cm |
| Operation Mode | High Automatic / Optical /Touch Panel |
| Voltage/Power | AC 380V±10% 50/60HZ / Top:1200W, Bottom:1200W, IR: 4800W |
| Heating Mode | Top/Bottom Nozzle Hot Air, Bottom Plates Infrared |
| Temperature Precision | 2-3 ℃ (5 Sensor Port) |
| Preheat Zone | 420×435 mm |
| Optical Alignment Precision | 0.02 MM |
| CCD Magnification: | 5X~50X |
| For PCB Size/Chip Size | 6*6MM~645*520MM Chip Size: 3*3~80*80MM |
| Standard Wooden Packing | Packing Size: L1100*W950*H1050(MM) / G.W: 180KG |
